EC200UEUAA-N05-SGNSA

Part Description:

•  EC200UEUAA-N05-SGNSA – 4G-LTE Cat1 IoT Module with BLE and GNSS/GPS
  •   Category – LTE Family
  •   Sub-Category – EC200U Series
• Remote Monitoring, Data Logger, VTS, OBD, Gateway.
• Speed:  Max – 10 Mbps (DL) / Max 5 Mbps (UL)
• No. of Pins: 144 pins, 80 LCC pins, and 64 LGA pins.
• Supply Voltage: 3.3–4.3 V DC, 3.8 V DC Typical
• Dimension: 28.0 × 31.0 × 2.4 mm
• Weight: Approx. 4.1g
• Network – LTE Cat1 / 2G
• Regulatory: SRRC/ NAL/ CCC
• Extended Temperature Range: -40°C ~ +85°C
• Bands:
  • LTE FDD: B1/B3/B5/B7/B8/B20/B28
  • LTE TDD: B38/B40/B41
  • GSM: B2/B3/B5/B8

• Supply Source: V-DC
• Additional Feature: GNSS / BLE 4.2 / Wi-Fi Scan Support.
